產品名稱：Circuit cable BPYJVP12-TK for frequency converter
瀏覽：
添加時間：2025-12-04 14:17:02
推薦度：

介紹：

產品用途

Product Usage

變頻電纜主要用于變頻電源和變頻電機之間連接用的電纜,以及額定電壓1KV及以下的輸配電線路中,作輸送電能用.尤其適用于造紙、冶金、金屬加工、礦山、鐵路和食品加工等行業。

Variable frequency cables are mainly used for connecting cables between variable frequency power supplies and variable frequency motors, as well as for transmitting electrical energy in transmission and distribution lines with a rated voltage of 1KV or below Especially suitable for industries such as papermaking, metallurgy, metal processing, mining, railways, and food processing.

使用條件

1、額定電壓U0/U：0.6/1KV.

1. Rated voltage U0/U: 0.6/1KV

2、電纜導體長期允許zui高溫度為90度,短路時zui高溫度250度

2. The maximum allowable temperature for cable conductors in the long term is 90 degrees Celsius, and the maximum allowable temperature during short circuits is 250 degrees Celsius

3、安裝敷設環境溫度不低于0度,固定敷設時環境溫度不低于-10度.

3. The installation and laying environment temperature shall not be lower than 0 degrees, and the fixed laying environment temperature shall not be lower than -10 degrees

4、電纜允許zui小彎曲半徑不小于15D（D-電纜外徑,mm）

4. The maximum allowable bending radius for cables is not less than 15D (D - cable outer diameter, mm）

產品性能

Product performance

1、 BRYJVP12R-TK、ZRBPYJVP12R-TK型設計采用符合GB/T3956-1997規定的第5類軟絞合銅導體。

1. The BRYJVP12R-TK and ZRBPYJVP12R-TK designs use Class 5 soft stranded copper conductors that comply with GB/T3956-1997 regulations.

2、交聯聚乙烯絕緣、耐溫耐候性好。

2. Cross linked polyethylene insulation has good temperature and weather resistance.

3、低傳輸阻抗，電磁兼容性好。

3. Low transmission impedance, good electromagnetic compatibility.

4、低工作電容

4. Low working capacitance

5、良好的抗和低輻射性能。

5. Good resistance and low radiation performance.

6、對稱的三芯電纜結構設計，具有比四芯電纜更好的傳輸性能。

6. The symmetrical three core cable structure design has better transmission performance than four core cables.

型號名稱

Model Name

BPYJVTP2-TK 銅芯交聯聚乙烯絕緣聚氯乙烯護套銅絲纏繞銅帶繞包屏蔽變頻器用回路電纜。

BPYJVTP2-TK copper core cross-linked polyethylene insulated polyvinyl chloride sheathed copper wire wrapped copper tape wrapped shielded frequency converter circuit cable.

ZRBPYJVTP2-TK銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅絲纏繞銅帶繞包屏蔽變頻器用回路電纜。

ZRBPYJVTP2-TK copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed copper wire wrapped copper tape wrapped shielded frequency converter circuit cable.

BPYJVP12-TK銅芯交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包銅絲編織雙重屏蔽變頻器用回路電纜。

BPYJVP12-TK copper core cross-linked polyethylene insulated polyvinyl chloride sheathed copper tape wrapped copper wire braided double shielded frequency converter circuit cable.

ZRBPYJVP12-TK銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅帶繞包銅絲編織雙重屏蔽變頻器用回路電纜。

ZRBPYJVP12-TK copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed copper tape wrapped copper wire braided double shielded frequency converter circuit cable.

BPYJVPX12R-TK銅芯交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包鍍錫銅絲編織雙重屏蔽變頻器用回路電纜。

BPYJVPX12R-TK copper core cross-linked polyethylene insulated polyvinyl chloride sheathed copper tape wrapped tin plated copper wire braided double shielded frequency converter circuit cable.

ZRBPYJVPX12R-TK銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅帶繞包鍍錫銅絲編織雙重屏蔽變頻器用回路電纜。

ZRBPYJVPX12R-TK copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed copper tape wrapped tin plated copper wire braided double shielded frequency converter circuit cable.

BPYJVTP2-TK 3 1.5~240

ZRBPYJVTP2-TK 3 1.5~240

BPYJVP12R-TK 3+3 主線芯截面:2.5-240,副線芯截面:0.5-35

BPYJVP12R-TK 3+3 main core section: 2.5-240, secondary core section: 0.5-35

BPYJVPX12R-TK 3+3 主線芯截面:2.5-240,副線芯截面:0.5-35

BPYJVPX12R-TK 3+3 main core section: 2.5-240, secondary core section: 0.5-35

ZRBPYJVP12R-TK 3+3 主線芯截面:2.5-240,副線芯截面:0.5-35

ZRBPYJVP12R-TK 3+3 main core section: 2.5-240, secondary core section: 0.5-35

ZRBPYJVPX12-TK 3+3 主線芯截面:2.5-240,副線芯截面:0.5-35

ZRBPYJVPX12-TK 3+3 main core section: 2.5-240, secondary core section: 0.5-35

注:另可根據用戶需要提供鎧裝結構變頻電纜.

Note: Armored structure frequency conversion cables can also be provided according to user needs
