產品名稱：Flame retardant frequency conversion cableZRC-BPYJVRP
瀏覽：
添加時間：2025-11-27 10:31:21
推薦度：

介紹：

描述：ZRC-BPYJVRP-0.6/1KV變頻電纜應用范圍：適用于造紙、冶金、紡織、金屬加工、礦山、鐵路和食品加工等行業。變頻電纜主要用于變頻電源和變頻電機之間連接用的電纜，以及額定電壓1kV及以下的輸配電線路中，作輸送電能用。

Description: ZRC-BPYJVRP-0.6/1KV variable frequency cable Application scope: Suitable for industries such as papermaking, metallurgy, textile, metal processing, mining, railway, and food processing. Variable frequency cables are mainly used for connecting cables between variable frequency power supplies and variable frequency motors, as well as for transmitting electrical energy in transmission and distribution lines with a rated voltage of 1kV or below.

ZRC-BPYJVRP-0.6/1KV變頻電纜允許溫度及工作電壓

ZRC-BPYJVRP-0.6/1KV Variable Frequency Cable Allowable Temperature and Operating Voltage

1、交聯聚乙烯絕緣變頻電纜允許導體連續工作zui高溫度90℃，短路時zui高溫度250℃。硅橡膠

1. Cross linked polyethylene insulated variable frequency cables allow conductors to operate continuously at a maximum temperature of 90 ℃, and during short circuits at a maximum temperature of 250 ℃. silicone rubber

zui高溫度150℃，短路時zui高溫度250℃。

The maximum temperature is 150 ℃, and the maximum temperature during short circuit is 250 ℃.

2、交聯型變頻電纜在運輸、儲存、輻射、搬運和作業時自由彎曲≥+5℃，固定敷設：≥0℃。硅橡

2. Cross linked variable frequency cables can be freely bent at ≥+5 ℃ during transportation, storage, radiation, handling, and operation, and can be fixedly laid at ≥ 0 ℃. Silicone rubber

輻射、搬運和作業時自由彎曲≥-20℃，固定敷設：≥-25℃。

Free bending during radiation, handling, and operation: ≥ -20 ℃, fixed installation: ≥ -25 ℃.

3、電纜彎曲半徑為電纜直徑的12倍，軟電纜為電纜直徑的6倍。

3. The bending radius of the cable is 12 times the diameter of the cable, and the bending radius of the flexible cable is 6 times the diameter of the cable.

4、額定電壓為600/1000V，交流試驗電壓3500V。

4. The rated voltage is 600/1000V, and the AC test voltage is 3500V.

ZRC-BPYJVRP-0.6/1KV變頻電纜3*95+3*16產品特點

ZRC-BPYJVRP-0.6/1KV Variable Frequency Cable 3 * 95+3 * 16 Product Features

1、較低的有效電容；

1. Lower effective capacitance;

2、具有屏蔽性能，高密度編織屏蔽及復合屏蔽設計使電纜具有良好的抗電磁干擾、電磁輻射的性

2. With shielding performance, high-density braided shielding and composite shielding design make the cable have good resistance to electromagnetic interference and radiation

備的應用。

Prepared applications.

3、較低且均勻的正（逆）序和零序阻抗，與普通四芯電纜相比改善了供電品質：該電纜含有屏蔽

3. Lower and uniform positive (reverse) and zero sequence impedances improve power supply quality compared to ordinary four core cables: the cable contains shielding

RX是對屏蔽抗感應和電容耦合的有效性的量度，低傳輸阻抗可提供良好的電磁相容性。

RX is a measure of the effectiveness of shielding against induction and capacitive coupling, and low transmission impedance can provide good electromagnetic compatibility.

4、*對稱的三芯設計，更好的電磁兼容性，比四芯電纜更好的性能。三根耐侯耐溫樹脂絕緣線芯

4. Symmetrical three core design, better electromagnetic compatibility, and better performance than four core cables. Three weather resistant and temperature resistant resin insulated wire cores

真正的同心結構。

A true concentric structure.

5、*屏蔽了高次諧波電流分量對其他控制電路的干擾。

5. Shielded the interference of high-order harmonic current components on other control circuits.

6、屏蔽層的截面設計與主線芯達到一定比例，可用作PE接地線芯。

6. The cross-sectional design of the shielding layer is proportional to the main wire core and can be used as a PE grounding wire core.

7、電纜導體的zui高工作溫度與絕緣材料相適應。

7. The maximum working temperature of cable conductors is compatible with the insulation material.

8、采用低煙無鹵阻燃護層，電纜在發生火災時具有發煙少，使用更安全更環保，也可以制造成耐

8. By using a low smoke halogen-free flame retardant protective layer, the cable emits less smoke in the event of a fire, making it safer and more environmentally friendly to use. It can also be manufactured to be durable

9、試驗電壓：3.5kV/5min；脈沖雷擊電壓：正負10次，40kV不擊穿。

9. Test voltage: 3.5kV/5min; Pulse lightning voltage: positive or negative 10 times, 40kV without breakdown.

型號說明：

Model Description:

型號名稱適用場所

Model Name Applicable Location

BPYJVP 交聯聚乙烯絕緣聚氯乙烯護套銅絲編織屏蔽變頻器用電纜

BPYJVP cross-linked polyethylene insulated PVC sheathed copper wire braided shielded frequency converter cable

有較高屏蔽要求的場所

Places with high shielding requirements

BPYJVP2交聯聚乙烯絕緣聚氯乙烯護套銅帶屏蔽變頻器用電纜

BPYJVP2 cross-linked polyethylene insulated polyvinyl chloride sheathed copper tape shielded frequency converter cable
