用途:該電纜適用作交流額定電壓500V及以下或直流1000V及以下的計算機連接線,也可以作電器、儀表、配電裝置的連接線。
Purpose: This cable is suitable for computer connection lines with AC rated voltage of 500V and below or DC rated voltage of 1000V and below, and can also be used as connection lines for electrical appliances, instruments, and distribution equipment.
名稱:聚乙烯絕緣電子計算機電纜說明:接用多對屏蔽電纜。儀表控制電纜ZR-DJYVRP32-0.3/0.5KV-1*2*1.5mm2使用特性(1) 電纜額定電壓U0/U: 300/500V(2) 電纜導體高允許工作溫度:聚氯乙烯絕緣及聚乙烯絕緣為70℃;交聯聚乙烯絕緣為90℃。(3) 電纜敷設低低環境溫度-10℃。(4) 允許彎曲半徑:不小于電纜外徑的6倍,銅帶及鋁塑復合帶屏蔽電纜、鎧裝電纜不小于電纜外徑的12倍。 Name: Polyethylene Insulated Electronic Computer Cable Instructions: Use multiple pairs of shielded cables. Instrument control cable ZR-DJYVRP32-0.3/0.5KV-1 * 2 * 1.5mm2 Usage characteristics (1) Cable rated voltage U0/U: 300/500V (2) Cable conductor high allowable working temperature: PVC insulation and polyethylene insulation are 70 ℃; Cross linked polyethylene insulation is 90 ℃. (3) Cable laying in low ambient temperature -10 ℃. (4) Allowable bending radius: not less than 6 times the outer diameter of the cable, and not less than 12 times the outer diameter of copper tape and aluminum-plastic composite tape shielded cables and armored cables.
